The new beast of builds: Xigmatek Osiris with BTF technology and 140mm cooling

If you are looking for a completely clean setup (Clean Build) with terrifying cooling performance, caseOsirisfrom Xigmatek is the qualitative leap your device needs. It comes with a wide panel and is equipped with future technologies, along with a power supplyAsgard 850Wto power the strongest cards while you are at ease.

Why choose Xigmatek Osiris?

1️⃣ Say goodbye to cable clutter (BTF support):The strongest feature of this case is that it supports new motherboards (Back Plug Motherboards) whether ATX or Micro ATX. This means that all power cables connect from the back of the motherboard, and your device's front isglass onlywith no visible cables!

2️⃣ Air cooling "tornadoes" (Airflow Master):The case is designed to let your device breathe properly:

• 140mm fans:The front supports the installation of 3 fans sized 140mm (or 120mm), which provides much stronger airflow and quieter sound.

• Open water cooling:Supports a water radiator360mmin the front or on the top, and up to 240mm on the side (for standard motherboards).

• Comprehensive ventilation:You can install up to 9 fans in the case to cover every angle (including above the PSU shroud).

3️⃣ Huge space for all hardware components:

• Graphics cards:You have space for up to400mmto install the largest graphics cards (RTX 4090 and others) comfortably (if no side fans are installed).

• CPU cooling:Height180mmfor air coolers, meaning you can install the largest air coolers without worry.

• Motherboards:Supports up to sizeE-ATXgiant.

4️⃣ Power supply (Asgard 850W 80+ Bronze):You don't need to search and buy an external power supply, the case comes with a power850 wattswith an 80+ Bronze certification, which is more than enough to run high-end builds stably and safely.

Specifications of Xigmatek Osiris 140mm ARGB BTF + Asgard 850W 80+ Bronze

Product Name

Osiris

Dimensions

465x238x481mm (LxWxH)

Motherboard Support

E-ATX

ATX (Support Back Plug)

Micro ATX (Support Back Plug)

Mini ITX

Drive Bays

HDD Cage: 3.5″ x2 & 2.5″ x1

SSD Bracket: 2.5″ x2

Fan Support

Front: 120mm x3 or 140mm x3

MB: 120mm x2 (E-ATX MB Width ≤28.5cm)

Top: 120mm x3 or 140mm x2

PSU Shroud: 120mm x2

Rear: 120mm x1 or 140mm x1

PSU Length Limitation

220mm

CPU Cooler Clearance

180mm

Material

Steel

Power Supply

Standard PS2 ATX PSU

Expansion Slots

7 Standard Slots, Support

Vertical GPU Card (90 Degree)

I/O Panel

USB 3.0 x1

USB 2.0 x2

HD Audio

Radiator Support

Front: 240/280/360

MB: 240 (E-ATX MB Width ≤28.5cm)

Top: 240/280/360

Rear: 120

GPU Length Limitation

285mm (Fan on MB Panel)

400mm (No Fan on MB Panel)
